| 產品型號 | TM-40 | TM-60 | TM-80 | TM-100 | TM-120 |
| 適用管件 | φ40X2.0t | φ60X2.0t | φ80X2.0t | φ100X2.0t | φ120X2.0t |
| 工作行程 | 100mm | 130mm | 150mm | 150mm | 150mm |
| 油壓出力 | 4.5Mpa | 12Mpa | 12Mpa | 14Mpa | 14Mpa |
| 工作速度 | 100min in 3-4sec | 100min in 3-4sec | 130min in 5-6sec | 140min in 6-7sec | 140min in 8-9sec |
| 機器尺寸 | 2000X550X1300mm | 2000X600X1400mm | 2900X700X1400mm | 3000X750X1500mm | 3500X900X1800mm |
| 機器重量 | 1100kg | 1250kg | 1600kg | 1800kg | 2500kg |
